德广信DU小间距亮相迪拜2017 Infocomm mea展会.

The once a year Middle East (Dubai) Infocomm Mea,AV Technollogy & Equipment trade show,

will take place at the Dubai international expo center.

DGX is bringging it's DU series Narrow Pixel Pitch for the party, booth #E6-20.


一年一度的中东(迪拜)视听显示技术与设备展infocomm mea 在迪拜国际会展中心盛大开幕。德广信(展位

:E6-20号)携DU系列小间距产品亮相展会。该展汇聚了应用在教育及培训、交通、安防、医疗、娱乐、建筑、

企业和政府部门等领域的视听技术、解决方案,展品涵盖面广,是一场高端专业展会。

画板 1.png

画板 2 拷贝 4.png



Product Features:

● Cabinet with 16:9 ratio design, display images without distortion.

Full front installation design, requires very few space.

Super thin design, cabinet thickness only 37.5mm.

Secondary low voltage power source design, high efficiency genarating low heat.

Hard power connection between cabinets reducing bad connection factor.

Module with auto data storage & auto failure detection function.

System board can be maintained from both front and back side.

Modules with Aluminum alloy cover , improving it's heat dissipation.

Signal connection between cabinets performed with hiden HDMI connectors,

allowing a stable connection with clean back view.

Both signal and power with hot back up to guarantee uninterrupted events.

Highly stable board to board connection between modules and hub.

High contrast, high refresh rate with 256 gray scales at low brightness.


产品特点:

● 单元显示箱体采用16:9设计,高清显示点对点,图像无变形无压缩;

●全前维护设计,安装空间小;

●屏体超薄设计,整个箱体厚度只有37.5mm;

●二级电源设计,箱体供电为低电压,采用高效率模块电源,发热量小;

●箱体电源无级联输出,减小接插件的故障风险;

●模组智能检测(单点检测,故障预警,温度检测等)和数据存储功能(校正据存储,生产数据存储);

●系统卡可实现前后维护;

●模组采用铝合金压铸底壳,平整度好,底壳与PCB和IC紧贴,散热效果良好;

●箱体间信号连接采用隐藏式HDMI对接,性能更为可靠,屏体拼装后后部整洁干净;

●控制卡和电源采用双备份设计,能运用到各种高要求场所;

●模组和HUB采用板对板专业连接器,性能更为可靠;

●高灰度、高刷新、高对比度、低亮度设计;
